miniEPICa Series EP-m501-AA

2.5"miniDesktop 5Bays eSATA-SATAII RAID Subsystem


miniEPICa Series EP-m501-AA

2.5"miniDesktop 5Bays eSATA-SATAII RAID Subsystem
  • proware-minidesktop-storage-front
  • proware-minidesktop-storage-frontsidebar
  • proware-minidesktop-storage-frontopen
  • proware-minidesktop-storage-rear

Features

  • eSATA (3Gbps) host interface or USB 2.0 + 1394b host interface
  • Over 2TB support
  • Supports hot spare and automatic hot rebuild
  • Local event notification
  • Easy management via In-Band data bus
  • Transparent data protection for all popular operating systems
  • RAID Management

  • Real time drive activity and status indicators
  • Graphical User Interface (GUI) management utility
  • Your message has been sent. Thank you!
    * Please fill all required form field, thanks!
    Unsurpassed Value
  • Most cost-effective SATA II RAID subsystem
  • AES Data Encryption(Optional)
  • Compact Desktop size with stylish design
  • Application Flexibility
  • Extends useful life by adapting to future IT/SOHO requirements
  • Easy Installation & Maintenance
  • Provide a fast and easy way to install and manager the storage
  • Low Power Consumption
  • Cable-less backplane with integrated RAID processor. No more unnecessary components inside
  • Model EP-m501-AA
    RAID processor Integrated Micro processor
    RAID level 0, 1, 3, 5, 10, LARGE, CLONE
    No. of channels(host+drive) 1 + 5
    Host bus interface eSATA
    Drive bus interface SATA II (Up to 3.0Gbps)
    Data transfer rate Up to 3.0Gbps (SATA II)
    Data Encryption Yes (Optional)
    Hot-swap drive trays Five (5) 2.5-inch Disk trays
    Cooling fans 1
    Failed drive indicators Yes
    Failed drive auto rebuild Yes
    Environment monitor Yes
    Auto spare support Yes
    Over 2TB support Yes
    Power supply 60W EXT.Power Adapter (full range)
    Environmental
    Relative Humidity 10% ~ 85% Non-condensing
    Operating Temp 10°C ~ 40°C (50°F ~ 104°F)
    Physical Dimensions (Convertible) Tower:130(H) x 110(W) x 189(D)mm
      Desktop:110(H) x 130(W) x 189(D)mm
    Weight (Without Disk) 2.7Kg
